Container token for macro definition.

MacroDefinition

Bases: TokenGroup

4.5 Aperture Macro (AM).

The AM command creates a macro aperture template and adds it to the aperture template dictionary (see 2.2). A template is a parametrized shape. The AD command instantiates a template into an aperture by supplying values to the template parameters.

Templates of any shape or parametrization can be created. Multiple simple shapes called primitives can be combined in a single template. An aperture macro can contain variables whose actual values are defined by:

  • Values provided by the AD command,
  • Arithmetic expressions with other variables.

The template is created by positioning primitives in a coordinate space. The origin of that coordinate space will be the origin of all apertures created with the state.

A template must be defined before the first AD that refers to it. The AM command can be used multiple times in a file.

Attributes are not attached to templates. They are attached to the aperture at the time of its creation with the AD command.

An AM command contains the following words:

  • The AM declaration with the macro name
  • Primitives with their comma-separated parameters
  • Macro variables, defined by an arithmetic expression
Syntax
AM = '%' ('AM' macro_name macro_body) '%';
macro_name = name '*';
macro_body = {in_macro_block}+;
in_macro_block =
|primitive
|variable_definition
;
variable_definition = (macro_variable '=' expression) '*';
macro_variable = '$' positive_integer;
primitive = primitive_code {',' par}*
par = ',' (expression);
  • AM - AM for Aperture Macro
  • <Macro name> - Name of the aperture macro. The name must be unique, it cannot be reused for another macro. See 3.4.5 for the syntax rules.
  • <Macro body> - The macro body contains the primitives generating the image and the calculation of their parameters.
  • <Variable definition> - $n=<Arithmetic expression>. An arithmetic expression may use arithmetic operators (described later), constants and variables $m defined previously.
  • <Primitive> - A primitive is a basic shape to create the macro. It includes primitive code identifying the primitive and primitive-specific parameters (e.g. center of a circle). See 4.5.1. The primitives are positioned in a coordinates system whose origin is the origin of the resulting apertures.
  • <Primitive code> - A code specifying the primitive (e.g. polygon).
  • <Parameter> - Parameter can be a decimal number (e.g. 0.050), a variable (e.g. $1) or an arithmetic expression based on numbers and variables. The actual value is calculated as explained in 4.5.4.3.

Coordinates and sizes are expressed in the unit set by the MO command.

A parameter can be either:

  • A decimal number
  • A macro variable
  • An arithmetic expression

A macro variable name must be a $ character followed by an integer >0, for example $12. (This is a subset of names allowed in 3.4.3.)

Note: New lines can be added between words of a single command to enhance readability. They do not affect the macro definition.

Example

The following AM command defines an aperture macro named 'Triangle_30'.

%AMTriangle_30*
4,1,3,
1,-1,
1,1,
2,1,
1,-1,
30*
%

See section 4.5 of The Gerber Layer Format Specification
