Load Name (LN).

Note: The LN command was deprecated in revision I4 from October 2013.

The historic LN command doesn't influence the image in any manner and can safely be overlooked.

Function of the LN command: - LN is designed to allocate a name to the following section of the file. - It was originally conceptualized to serve as a human-readable comment. - For creating human-readable comments, it's advisable to utilize the standard G04 command. - The LN command has the flexibility to be executed multiple times within a file.

SPEC: 2023.03 SECTION: 8.1.6

LoadName

Bases: Token

Comment token.

Load Name (LN)

Note: The LN command was deprecated in revision I4 from October 2013.

The historic LN command doesn't influence the image in any manner and can safely be overlooked.

Function of the LN command: - LN is designed to allocate a name to the following section of the file. - It was originally conceptualized to serve as a human-readable comment. - For creating human-readable comments, it's advisable to utilize the standard G04 command. - The LN command has the flexibility to be executed multiple times within a file.

SPEC: 2023.03 SECTION: 8.1.6

Source code in src/pygerber/gerberx3/tokenizer/tokens/ln_load_name.py
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
class LoadName(Token):
    """Comment token.

    ### Load Name (LN)

    Note: The LN command was deprecated in revision I4 from October 2013.

    The historic `LN` command doesn't influence the image in any manner and can safely
    be overlooked.

    Function of the `LN` command:
    - `LN` is designed to allocate a name to the following section of the file.
    - It was originally conceptualized to serve as a human-readable comment.
    - For creating human-readable comments, it's advisable to utilize the standard `G04`
        command.
    - The `LN` command has the flexibility to be executed multiple times within a file.

    SPEC: `2023.03` SECTION: `8.1.6`
    """

    content: str

    @classmethod
    def from_tokens(cls, **tokens: Any) -> Self:
        """Initialize token object."""
        content: str = tokens["string"]
        return cls(content=content)

    def __str__(self) -> str:
        return f"%LN {self.content}*%"

from_tokens classmethod

from_tokens(**tokens: Any) -> Self

Initialize token object.

Source code in src/pygerber/gerberx3/tokenizer/tokens/ln_load_name.py
51
52
53
54
55
@classmethod
def from_tokens(cls, **tokens: Any) -> Self:
    """Initialize token object."""
    content: str = tokens["string"]
    return cls(content=content)
